Solving Graphics Blanking In CC7800 52K ROMs

Ever found yourself scratching your head when your meticulously crafted Atari 7800 game suddenly shows graphics going blank right after you compile it into a larger 52K ROM using CC7800? You're definitely not alone in this puzzling predicament. It’s a common scenario where everything seems fine in smaller ROMs, perhaps up to 48K, but once you push that boundary to 52K, certain graphical elements, like your beautifully designed character sets, tile sets, or even some sprites, vanish into thin air. This can be incredibly frustrating, especially when you’ve poured hours into creating the visual flair for your retro masterpiece. The root of this issue often lies deep within the fascinating, yet sometimes tricky, world of the Atari 7800's memory architecture and how CC7800 interacts with it, particularly concerning the placement of graphics data and the nuances of the DMA hole.

Understanding the Problem: Graphics Blanking in 52K ROMs

When your graphics start going blank in a 52K ROM compiled with CC7800, it's a clear signal that something is amiss with how your game's visual assets are being stored and accessed. Specifically, if you've noticed that some of your graphics data is stored at $3000 when examining your listings, this is a significant clue. The Atari 7800, a marvel of late 80s technology, has a unique memory map, and placing graphics data in certain regions can lead to unexpected behavior, especially as ROM sizes increase. For non-DMA hole aligned graphics such as common character sets, intricate tile sets, or even simple sprites, their memory location is crucial. The address range below $4000, particularly around $3000, can be a tricky area. This region might be used by the system's RAM or other hardware components, making it unsuitable for direct graphical data access, especially by the console's custom graphics chip, MARIA. When your ROM size expands beyond the standard 48K into the 52K territory, CC7800 might be making different memory allocation decisions, inadvertently placing critical graphics information in a spot that the MARIA chip simply cannot reliably fetch data from. This isn't necessarily a bug with CC7800 itself, but rather a clash between the compiler's default memory management and the specific hardware constraints of the Atari 7800. It’s like trying to store a giant piece of artwork in a tiny closet that's already full – the artwork just won't fit or be accessible when you need it. Adding another layer of complexity, there's always the possibility that the A7800 emulator you're using might not be perfectly replicating the exact hardware behavior, especially for edge cases involving larger, bank-switched ROMs. Emulators strive for accuracy, but the subtle timings and memory access patterns of vintage hardware can sometimes be elusive, leading to discrepancies between how a game runs on an emulator versus actual hardware. This collective challenge, from memory mapping to compiler behavior and potential A7800 emulation issues, forms the intricate puzzle behind your mysteriously vanishing graphics. Pinpointing the exact cause requires a bit of detective work, diving into linker scripts, memory maps, and even the subtle nuances of the 7800's graphical architecture. But don't fret, we'll unravel these mysteries together, ensuring your Atari 7800 creations shine brightly, without any blank spaces!

Deep Dive into CC7800 and Memory Management

Let's get cozy with CC7800, the powerful compiler suite that breathes life into Atari 7800 homebrew projects. While CC7800 is an incredible tool, handling the intricate memory management of the Atari 7800, especially for larger 52K ROMs, can present some unique challenges, particularly when it comes to preventing graphics going blank. The Atari 7800's architecture isn't as straightforward as modern systems; it relies heavily on bank switching to access ROMs larger than its internal memory addressing capabilities. For ROMs up to 48K, the memory layout might be relatively stable, but once you expand to 52K, CC7800 must employ bank switching to make that extra 4K accessible. This is where things get interesting and sometimes problematic for your visual assets. The compiler has a default strategy for where it places different sections of your code and data (like your precious graphics data). It uses linker scripts to define these memory regions. If the default linker script, or perhaps a custom one you're using, doesn't explicitly account for the nuances of 52K ROMs and the specific requirements of the Atari 7800's graphics hardware, your character sets, tile sets, or sprites might end up in a problematic location. Imagine CC7800 trying to be smart about memory usage, and it sees a
