# KNXD IP Interface Connection Troubleshooting

Hello there! It sounds like you're running into a bit of a snag with your KNXD setup, specifically with the connection to your IP Interface. Don't worry, we've all been there! It's frustrating when things that used to work suddenly stop, especially after an update. Let's dive in and see if we can figure out what's going on with that `E00000064: [19:router] router: setup router: failed` error.

## Understanding the KNXD IP Interface Error

The error message `E00000064: [19:router] router: setup router: failed` is the key here. It indicates that the KNXD router, which is responsible for managing communication within your KNX network via the IP interface, is failing to initialize correctly. This could stem from a variety of issues, ranging from network misconfigurations to incorrect parameters in your `docker-compose.yaml` file. Since you mentioned pulling the latest containers and that parameters might have changed, this is a strong indicator that the issue is related to how KNXD is being configured to interact with your specific IP interface.

When KNXD starts, it reads its configuration and attempts to establish connections and set up the necessary routing. The router component is crucial for directing traffic between different KNX interfaces and clients. If this setup fails, it means KNXD can't properly manage the communication flow. The fact that you're using `michelmu/knxd-docker:latest` and that the error occurred after an update suggests that there might have been a change in the expected configuration parameters or the way certain interfaces are handled in the newer version. It's great that you've already identified that parameters might have changed and are actively investigating.

Your `docker-compose.yaml` file provides a good snapshot of your current setup. Let's break down the relevant parts and see if we can spot any potential discrepancies or areas for improvement. The `knxd` service definition includes several environment variables that dictate how KNXD should behave and connect. These include `ADDRESS`, `CLIENT_ADDRESS`, `INTERFACE`, `IP_ADDRESS`, `DEST_PORT`, `NAT`, and `SERVER_INTERFACE`. The error occurring during the `router: setup router: failed` phase specifically points to a problem in the network interface configuration or the routing logic itself. It's essential that the parameters you provide accurately reflect your network setup and the capabilities of your MDT IP Interface SCN-IP000.02.

### Analyzing Your Docker Compose Configuration

Let's take a closer look at the `docker-compose.yaml` you provided:

```yaml
services:
  knxd:
    image: michelmu/knxd-docker:latest
    container_name: knxd
    restart: always
    cap_add:
      - SYS_MODULE
      - SYS_RAWIO
    environment:
      - ADDRESS=1.1.230
      - CLIENT_ADDRESS=1.1.240:4
      - DEBUG_ERROR_LEVEL=debug
      - INTERFACE=ipt
      - IP_ADDRESS=192.168.10.250
      - DEST_PORT=3671
      - NAT=true
      - SERVER_INTERFACE=eth0
    network_mode: host
    deploy:
      resources:
        limits:
          memory: 64M

Here's a breakdown of what each parameter means and potential areas to check:

  • image: michelmu/knxd-docker:latest: You're using the latest image, which is good for getting the newest features and bug fixes, but as you've seen, it can also introduce breaking changes.
  • ADDRESS=1.1.230: This is the KNX bus address for your KNXD instance. It's crucial that this address is unique on your KNX network and doesn't conflict with other devices.
  • CLIENT_ADDRESS=1.1.240:4: This defines the KNX address that KNXD will use for its clients (like FHEM). The :4 indicates the connection identifier, which is usually fine.
  • INTERFACE=ipt: This specifies the type of interface KNXD should use. ipt typically refers to an IP-based interface, which is correct for your SCN-IP000.02. The configuration generated by KNXD clearly shows an [interface-ipt] section.
  • IP_ADDRESS=192.168.10.250: This is the IP address of your KNXD host (where the Docker container is running) on your local network. It's important that this IP is correct and reachable by your IP interface.
  • DEST_PORT=3671: This is the standard KNX IP port. It should be correct for most KNX IP interfaces.
  • NAT=true: This setting is important if your KNXD host is behind a Network Address Translation (NAT) device. If your Docker host and your KNX IP interface are on the same subnet and don't require NAT for KNX communication, setting this to false might be more appropriate. However, given the [interface-ipt] configuration generated, nat = true is correctly included.
  • SERVER_INTERFACE=eth0: This tells KNXD which network interface on the host it should bind to. eth0 is common, but ensure it's the correct interface for your network.
  • network_mode: host: This is a critical setting. Using network_mode: host means the container shares the host's network stack. This simplifies networking but can sometimes lead to conflicts or unexpected behavior if not managed carefully. It's generally a good choice for KNXD when dealing with specific hardware interfaces.

Debugging the router: setup router: failed Error

The most common reasons for the router: setup router: failed error, especially after an update, are:

  1. Incorrect IP Address or Port: Double-check that IP_ADDRESS (192.168.10.250) and DEST_PORT (3671) precisely match the configuration of your MDT IP Interface. Ensure the IP address is static and assigned correctly on your network. You can usually access your IP interface's web configuration page to verify its network settings.
  2. Firewall Issues: Although you're using network_mode: host, firewalls on your host machine or network could still be blocking the communication on port 3671. Ensure that UDP port 3671 is open for communication between the host running KNXD and the IP interface.
  3. KNX Address Conflicts: While less likely to cause this specific router error, ensure that the ADDRESS (1.1.230) and CLIENT_ADDRESS (1.1.240:4) are not already in use by another device on your KNX bus.
  4. Interface Driver Issues: The ipt driver is generally suitable for IP interfaces. However, sometimes specific hardware might require a particular configuration or driver. The generated config looks correct, but it's worth consulting the MDT documentation for your specific interface model to confirm any specific KNXD setup requirements.
  5. Changes in KNXD Docker Image: As you suspected, the latest michelmu/knxd-docker image might have introduced changes. It's possible that the default handling of certain parameters or the structure of the generated knxd.ini has been updated. The output shows [interface-ipt] is correctly generated, indicating the driver is recognized.

Investigating the Specific Error Log

Looking at the full log output:

knxd    | I00000131: [ 1:main] 0.14.72: knxd /etc/knxd.ini
knxd    | I00000129: [ 1:main] Connected: cfg:interface-ipt.
knxd    | I00000129: [ 1:main] Connected: cfg:A.tcp.
knxd    | I00000129: [ 1:main] Connected: cfg:server.
knxd    | W00000126: [ 1:main] knxd should not run as root
knxd    | N00000127: [21:router.pace_] The 'pace' filter without a queue acts globally.
knxd    | E00000064: [19:router] router: setup router: failed
knxd    | F00000105: [ 4:server] Link down, terminating
knxd    | N00000128: [ 1:main] Shutting down.

The lines I00000129: [ 1:main] Connected: cfg:interface-ipt. and Connected: cfg:A.tcp. suggest that KNXD is at least attempting to configure the IP interface and the TCP connection. However, the subsequent E00000064: [19:router] router: setup router: failed is the critical failure point. The W00000126: [ 1:main] knxd should not run as root is a warning and likely not the cause of the connection failure, but it's good practice to address it if possible (though in a Docker container, running as root is often the default setup).

The warning N00000127: [21:router.pace_] The 'pace' filter without a queue acts globally. is informational and indicates how a specific filter is being applied. It's unlikely to be the root cause.

Potential Solutions and Next Steps

  1. Verify IP Interface Status: Access your MDT IP Interface SCN-IP000.02's web interface and confirm its network settings. Ensure it's reachable from the machine running Docker and that its own configuration aligns with the IP_ADDRESS and DEST_PORT you've set in your docker-compose.yaml. Sometimes, IP interfaces have a specific
